ARO PD20P-YPS-KTL Non-Metallic 2" EXP Series Double Diaphragm Pump
The ARO PD20P-YPS-KTL is a 2-inch Non-Metallic EXP Air-Operated Double Diaphragm (AODD) Pump designed for high-capacity, leak-free fluid transfer in demanding industrial applications. Featuring a corrosion-resistant polypropylene construction, PVDF seats, PTFE balls, and long-life PTFE/Santoprene diaphragms, it delivers flow rates up to 184 GPM (696 LPM) with exceptional chemical compatibility, energy-efficient performance, and reliable low-maintenance operation. Ideal for handling corrosive chemicals, wastewater, slurries, and industrial process fluids.
ARO® expands EXP Series with new 2" Center Ported Polypropylene Models. The standard model PD20P-YXS-XXX has 2" ANSI/DIN Hybrid center ports facing the air inlet side of the pump. The mounting feet location of PD models matches the Wilden® P800 and PS800 models. Burt process equipment is the largest distributor of Ingersoll Rand ARO diaphragm pumps. ARO® EXP 2” non-metallic center ported pumps achieve flow rates of up to 166 GPM (628 LPM) and offer a wide array of material and porting configurations. 2” non-metallic pumps are often used for transfer, filling, recirculation, and batching in Chemical, Industrial, and Water/Wastewater treatment markets. What is a double diaphragm pump? A double diaphragm pump is a positive displacement pump that uses two sets of flexible membranes to pump fluids and a series of check valves to ensure fluid can only travel in one direction through the chamber. Pump cycling will begin as air pressure is applied. Air operated diaphragm pumps utilize a pressure differential in the air chambers to alternately create suction in the fluid chambers.
| Brand | ARO as configured: |
|---|---|
| Product Type | Pump as configured: |
| Product Series | EXP Series as configured: |
| Material - Diaphragm | Long-Life PTFE as configured: |
| Inlet/Outlet Connection Type | ANSI / DIN Flange as configured: |
| Inlet Size | 2 in as configured: |
| Solids Handling | 1/4 in as configured: |
| Material - Balls | PTFE as configured: |
| Material - Seats | PVDF as configured: |
| Max Flow | 166 gpm (628 lpm) as configured: |
| Noise Level | 85 dB as configured: |
| Material - Hardware | Stainless Steel as configured: |
| Max Pressure | 120 psi (8.3 bar) as configured: |
| Notes | 2" Diaphragm Pump as configured: |
| Displacement | Positive Displacement as configured: |
